4. Troubleshooting
2
2
2
Image 4-2
Lamp fixation
2 Lamp House fixation screws.
3
4
5
6
Image 4-3
Lamp connections
3 Blue socket connection Lamp Info Module of the Lamp House.
4 Blue socket i nside Lamp compartment (front view).
5 Wire unit for connection with blue socket (back side).
6 Lamp info module cable connection to signal backplane
30 R5905043 DP2K-12C/11CX 19/02/2018
