Barco ICMP Installation Manual

2. ICMP functionality
2D Formats / Single DP Color depth
Port Display Mode
2048 x 1536 @ 60 fps
8bpc,10bpc
Single
2D
2048 x 2160 @ 30, 48, 50, 60 fps
8bpc,10bpc
Single
2D
3840 x 2160 @ 24 fps
8bpc,10bpc
Single
2D
3D Formats / Single DP Color depth
Port Display Mode
1920 x 1080 @ 60 fps
8bpc,10bpc
Single
3D
2048 x 1080 @ 60 fps
8bpc,10bpc
Single
3D
4K Horizontal SPAN 2D - Full Color depth
Port Display Mode
2048 x 2160 @ 30, 48, 50, 60 fps
8 bpc, 10 bpc A+B span 2D
4K Horizontal SPAN 2D - Flat Color depth
Port Display Mode
1920 x 2160 @ 30, 48, 50, 60 fps
8 bpc, 10 bpc A+B span 2D
4K Horizontal SPAN 3D Color depth
Port Display Mode
2048 x 2160 @ 60 fps
8 bpc, 10 bpc A+B span 3D
Audio formats
• 2 channels / LPCM / 16 bits / 32 kHz, 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz
• 5.1 format / LPCM / 24 bits / 48 kHz
• 7.1 format / LPCM / 20 bits / 48 kHz
Notes:
• DisplayMode = Single : is applicable to both DisplayPort A, and DisplayPort B input, separately.
• DisplayMode = A+B : inputs DisplayPort A and DisplayPort B are combined to 1 larger image; in this
case the 2 DisplayPort links need to be genlocked ( = synchronous and in phase).
• In all cases :
- Color Space - Color Sampling:
o
YCbCr-4:4:4
o
YCbCr-4:2:2
o
RGB - 4:4:4
- Scan Type = progressive.
• Both Nvidia and AMD GPU’s will not support color depths of 10 bits/color while in 3D-stereo mode.
• Some Graphical Cards may not permit 10 bits/color at all video timings, because of bandwidth restric-
tions.
• DisplayPort A and DisplayPort B automatically detect:
- Active Pixels, and Active L ines
-VerticalRefresh
- 8 bits/color - 10 bits/color
- Frame locked
• All input resolutions are scaled towards the desired resolution specified in the screen presentation file.
• Fractional frame rates = (Hz*1000)/1001
R5905722 ICMP 09/11/2016
15
