2. ICMP functionality
2.7 ICMP HDMI specifi cation s
HDMI
HDMI (High-Definition Multimedia Interface) is a compact audio/video interface for transferring
uncompressed video data and compressed/uncompressed digital audio data from a HDMI-
compliant device ("the source device") to a compatible computer monitor, video projector, dig-
ital television, or digital audio device. HDMI is a digital replacement for existing analog video
standards.
HDMI specifications
HDMI1.4a, including HDCP1.4
2K Video-timings:
• 640 x 480p @ 60 fps
• 720 x 480p @ 60 fps
• 720 x 576 @ 50 fps
• 800 x 600p @ 60 fps
• 1024 x 768p @ 60 fps
• 1280 x 720p @ 50, 60 fps
• 1280 x 960p @ 60 fps
• 1280 x 1024p @ 60 fps
• 1400 x 1050p @ 60 fps
• 1920 x 1080 @ 24, 25, 30, 50, 60 fps
• 1920 x 1080i @ 50, 60 fields/second
4K Video t imings (ICMP 1.2.0)
• 3840 x 2160 @ 24, 25, 30 fps
• 4096 x 2160 @ 24, 25, 30 fps
3D Video t imings (ICMP 1.2.2)
• Frame packing:
- 1920 x 1080p @ 23.98 / 24 fps
- 1280 x 720p @ 50 fps
- 1280 x 720p @ 59.94 / 60 fps
• Top/Bottom:
- 1920 x 1080p @ 23.98 / 24 fps
- 1280 x 720p @ 50 fps
- 1280 x 720p @ 59.94 / 60 fps
• Side by side (SbS)
- Side by side : Half (same formats as for Top/Bottom encoding)
Color Space - Color Sampling:
• YCbCr - 4:4:4
• YCbCr - 4:2:2
• RGB - 4:4:4
• Color depth: supports 24, 30 and 36 bpp (8, 10 and 12 bpc).
- Exception: in case of HDMI UHD / full 4K only 24 bpp (8 bpc) is supported.
Audio formats:
• 2 channels / LPCM / 16 bits / 32 kHz, 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz
• 5.1 format / LPCM / 24 bits / 48 kHz
20
R5905722 ICMP 09/11/2016
