2. ICMP functionality
9
3G-SDI A (B)
SDI connector to connect a video source.
10
HDMI
HDMI connector to connect a video source.
2.5 ICMP DisplayPort sp ecifications
DisplayPort
Digital display interface developed by the Video Electronics Standards Association (VESA).
This royalty-free interface is primarily used to connect a video source to a display device such
as a computer monitor, though it can also be used to transmit audio, USB, and other forms of
data. VESA designed it to replace VGA, DVI, and FPD-Link. Backward compatibility to VGA
and DVI by using active adapter dongles enables users to use DisplayPo
rt fitted video sources
without replacing existing display devices.
HDCP
High-bandwidth Digital Content Protection is a form of digital copy protection developed by Intel
Corporation to prevent copying of digital audio and video content as it
travels across Display-
Port, Digital Visual Interface (DVI), High-Definition Multimedia Interface (HDMI), Gigabit Video
Interface (GVIF), or Unified Display Interface (UDI) connections, even if such copying would be
permitted by fair use laws. The specification is proprietary, and implementing HDCP requires
alicense.
DisplayP ort specifi cations
Supported Modes:
• DP1.1a, 4-lanes RBR/HBR
• Audio : yes
• Con tent Protection : HDCP1.4
• Color Depth : 8 bit/component and 10 bit/component.
• 3D-stereo mode : frame sequential (embedded stereosync on DP required from the source)
DisplayPort A and DisplayPort B accept the following video-t
imings:
2D Formats / Single DP Color depth
Port Display Mode
640 x 480 @ 60 fps
8bpc,10bpc
Single
2D
800 x 600 @ 60 fps
8bpc,10bpc
Single
2D
1600 x 1200 @ 60 fps
8bpc,10bpc
Single
2D
1280 x 800 @ 60 fps
8bpc,10bpc
Single
2D
1280 x 720 @ 60 fps 8 bpc, 10 bpc Single 2D
1680 x 1050 @ 60 fps 8 bpc, 10 bpc Single 2D
1920 x 1080 @ 60 fps 8 bpc, 10 bpc Single 2D
1920 x 1200 @ 60 fps 8 bpc, 10 bpc Single 2D
2048 x 1080 @ 48, 60 fps 8 bpc, 10 bpc Single 2D
14
R5905722 ICMP 09/11/2016
