A. Technical specifications
A. TEC HNICAL SPECIFICATION S
Overview
•Specifications of the ICMP
• About General Purpose Inputs & Outputs (GPIO)
•Pinconfigurations of the ICMP communication ports
A.1 Specificati ons of the ICMP
Specifications
Integrated Cinema Media
Processor
DCI 4K 2D up to 60fps*
DCI 4K 3D (24 or 30 fps per eye)*
DCI High Frame Rates 2K 3D up to 120fps (60fps per eye)
JPEG 2000 bit-rates up to 625Mbps
Dual-channel color-correction
MPEG-2 (4:2:0 and 4:2:2 up to 60fps)
2x DisplayPort 1.1a (up to 4K 2D 60fps and 4K 3D 30fps)**
2x 3G-SDI inputs
1x HDMI 1.4a (up to 4K 2D 24fps, support for BluRay 3D)
16x AES/EBU audio channels (2x RJ45)
8x GPI, 8x GPO (4x RJ45)
2x Gbe for content connectivity & ingest
2x front-accessible USB 3.0 for fast ingest
2x front-accessible USB 2.0
Video watermarking: Civolution NexGuard
Audio watermarking: Civolution
Closed captioning devices: Support for SMPTE 430-10
* 4K 24fps is standard. For 4K 60p / 4K 3D on ICMP upgrade modules
a license is required. Newly-built 4K Barco Alchemy projectors have
the license standard included.
** On B&C series projectors, the DisplayPort inputs replace the DVI
inputs of the Cinema Controller.
Integrated storage
1.9TB effective storage (RAID-5) / 3x 1TB Hot-swappable 2.5"
hard-drives
3.9TB effective storage (RAID-5) / 3x 2TB Hot-swappable 2.5"
hard-drives
R5905722 ICMP 09/11/2016 37
