88 ImagePRO-II • User’s Guide
4. Menu Orientation
Using the System Menu
Figure 4-79. EDID Confirmation Message
pÉííáåÖ=aáëéä~ó=_êáÖÜíåÉëë
The VFD Brightness Submenu adjust the intensity of the front panel vacuum fluorescent
display (VFD) screen. The adjustment range is +0 to +6, with +6 being the brightest. The
default setting is +3.
içÅâáåÖ=íÜÉ=cêçåí=m~åÉä
When the ImagePRO-II’s front panel is locked, button presses have no effect. In the locked
mode:
• All button presses and all turns of the ADJUST knob are ignored.
• All Ethernet and serial communications commands function normally.
• All button lights continue to reflect the correct state of the inputs.
To enable and disable the front-panel lock, use the following procedure:
1. On the System Menu, scroll to Lock Front Panel and press SEL.
The front panel is locked, and the following message appears.
Figure 4-80. Front Panel Locked Message
2. To disable the front panel lock, press and hold the SEL and ESC buttons
simultaneously for 3 seconds. When the panel is unlocked, the display screen
displays the Status Menu.
EDID Prog Done
<ESC> = Continue
Note
Using a low intensity is advisable, to avoid “burn-in” of the
display screen.
Front Panel
Locked Out.
Unit ID 18
