4. Menu Orientation
Using a Logo or Internal Black
• When you power up an ImagePRO-II that has a stored logo, the LOGO button is
dimmed.
• When the ImagePRO-II has no stored logo, the output displays black during
transitions.
• You can overwrite a stored logo by capturing a new image.
• If you perform a factory reset, the logo is cleared from memory and cannot be
retrieved.
• When an HDCP-capable source is selected (inputs 1, 3, or 4), you cannot save a
logo image from that source.
^Äçìí=íÜÉ=ildl=_ìííçå
The LOGO button states are:
• When selected, the LOGO button is lit.
• If the ImagePRO-II has a stored logo, the LOGO button is backlit when you
power up the system.
• When there is no stored logo, the LOGO button is not lit when you power up.
`~éíìêáåÖ=~=içÖç=rëáåÖ=íÜÉ=ildl=_ìííçå
To capture a logo using the LOGO button, use the following procedure:
1. Press and hold an input button.
2. Press LOGO.
The system captures the frame from the selected input, and stores the frame in
non-volatile memory. While the capture is in progress:
~ A progress bar and related messages are shown on the display screen.
~ The input button is backlit, and the LOGO button is lit.
aÉíÉÅíáåÖ=~åÇ=`~éíìêáåÖ=~=içÖç=rëáåÖ=íÜÉ=içÖç=jÉåì
The Logo Menu, shown in the following illustration, enables you to capture the source for
the LOGO button. You can also determine whether a logo is stored in the system, and
delete or erase the logo, using this menu.
Figure 4-81. Logo Menu
To access the menu, select Logo from the Setup Menu. The following functions are
provided:
LOGO
> Capture Logo n/a
Delete Logo n/a
Erase Logo n/a
Backup Logo >>
Restore Logo >>
Logo Present No
To Next Page
