132 ImagePRO-II • User’s Guide
^K==péÉÅáÑáÅ~íáçåë
Input Specifications
fåéìí=péÉÅáÑáÅ~íáçåë=
The following table lists ImagePRO-II input specifications.
Table A-1. ImagePRO-II Input Specifications
Input Detail Specification
Input 1 Connector DVI-I
Format (Digital) All single-link DVI digital formats up to 165 MHz, per
DVI 1.0 Specification
All dual-link DVI formats up to 300 MHz
Max H Active: 4096
Max V Active: 3072
Format (Analog) NTSC/PAL composite and Y/C video
SD YPbPr with bi-level sync
HD YPbPr with tri-level sync
RGBHV/RGBS/RGsB computer video with bi-level
sync
Sampling Analog sources with pixel rates up to 170 MHz are
sampled 1:1.
Analog sources with pixel rates above 170 MHz are
filtered and sampled at 170 MHz, including but not
limited to:
• 1920x1080p
• 1920x1200 p
• 2048x1080p
Loop-through Active loop-through output of all input signals,
including HDCP
EDID EDID version 1.3 compatible
HDCP hardware
support
HDCP version 1.4 compatible
Input 2 Connector HD-15 VGA
Format NTSC/PAL composite and Y/C video
SD YPbPr with bi-level sync
HD YPbPr with tri-level sync per SMPTE 274
RGBHV/RGBS/RGsB computer video with bi-level
sync
Sampling Analog sources with pixel rates up to 170 MHz are
sampled 1:1.
Analog sources with pixel rates above 170 MHz are
filtered and sampled at 170 MHz, including but not
limited to:
• 1920x1200 p
• 2048x1080p
EDID EDID version 1.3 compatible
Loop-through Active loop-through output of all input signals.
