ImagePRO-II • User’s Guide 133
^K==péÉÅáÑáÅ~íáçåë
Input Specifications
dÉåäçÅâ=péÉÅáÑáÅ~íáçåë
The following table lists the Genlock input specifications.
Table A-2. Genlock Input Specification
Input 3 Connector HDMI (Type A)
Formats RGB and YCbCr at 4:4:4, YCbCr at 4:4:2, per HDMI
1.4 specification
Deep color at 8/10/12 bits
Resolutions up to 2048x1080p @ 60 Hz
EDID support EDID 1.3 compatible
HDCP hardware
support
HDCP 1.4 compatible
Input 4 Connector DisplayPort
Formats Resolutions up to 2560x1600 @ 60 Hz (30 bits), per
DisplayPort 1.1a Specification
EDID and HDCP
hardware support
EDID 1.3 compatible & HDCP 1.4 compatible
Input 5 Connector SD/HD/3G SDI on BNC connector
Formats SD-SDI per SMPTE 259M-C (NTSC/PAL resolution)
HD-SDI per SMPTE 292M, 296M
3G-SDI per SMPTE 425
Loop-through Re-clocked loop-through output
Input Detail Specification
Genlock Connector BNC connector
Formats NTSC/PAL blackburst
HD with tri-level sync
SMPTE bi-level sync
Loop-through Passive loop-through
Table A-1. ImagePRO-II Input Specifications
Input Detail Specification
