134 ImagePRO-II • User’s Guide
^K==péÉÅáÑáÅ~íáçåë
Output Specifications
lìíéìí=péÉÅáÑáÅ~íáçåë=
The following table lists the ImagePRO-II output specifications.
Table A-3. ImagePRO-II Output Specifications
Output Detail Specification
DVI-D Connector DVI-D
Formats All single-link DVI digital formats up to 165 MHz, per
DVI 1.0 Specification
All dual-link DVI formats up to 300 MHz
EDID support EDID 1.3 compatible
HDCP hardware
support
HDCP 1.4 compatible
HD-15 Connector HD-15 VGA
Format NTSC/PAL composite on green pin
NTSC/PAL Y/C video with bi-level sync on Y only:
• Y on Green pin
• C on Red pin
SD YPbPr with bi-level sync
HD YPbPr with tri-level sync per SMPTE 274
RGBHV/RGBS/RGsB computer video with bi-level
sync
EDID support EDID 1.3 compatible
HDMI Connector HDMI (Type A)
Formats RGB and YCbCr at 4:4:4, per HDMI 1.4 specification
Resolutions up to 2048x1080p @ 60 Hz
EDID support EDID 1.3 compatible
HDCP hardware
support
HDCP 1.4 compatible
DisplayPort Connector DisplayPort
Formats Resolutions up to 2560x1600p @60 Hz
EDID EDID 1.3 compatible
HDCP hardware
support
HDCP 1.4 compatible
SDI-1 Connector SD/HD/3G SDI on BNC connector
Formats SD-SDI per SMPTE 259M-C (NTSC/PAL resolution)
HD-SDI per SMPTE 292M, 296M
3G-SDI per SMPTE 425
Composite
Video
Connector NTSC/PAL composite video on BNC connector
