150 ImagePRO-II • User’s Guide
B. Remote Control Protocol
ImagePRO-II Remote Commands
f`e
• Description: Input Channel settings
• Required parameters:
--con (connector)
--ch (channel)
--itype (input type), only for commands to DVI connector
• Parameters:
--con (connector): 0-4
0 = DVI, 1 = HD15,
2 = HDMI, 3 = DP, 4 = SDI1,
--ch (channel): 0-1, input channel
--itype (input type): 0 = digital, 1 = analog
--iwin: Option to set input window
--hpos (Input window H Position, pixels)
--vpos (Input window V Position, pixels)
--hsize (Input window H Size, pixels)
--vsize (Input window V Size, pixels)
--mask: Option to set the mask window
--left (Mask Left, in percentage)
--right (Mask Right, in percentage)
--top (Mask Top, in percentage)
--bottom (Mask Bottom, in percentage)
• Examples:
ICH --con 0 --itype 0 --ch 0 --iwin --hpos 10
(Update DVI (digital in) input, Input Window H Position to 10)
ICH --con 1 --ch 0 --mask --left 45.10
(Update HD-15 input, Mask Left by 45.10%)
• Query Format 1 (Input window):
ICH --con (connector) --ch (channel) --iwin --?
• Query Response 1: Input Channel Window Setting in the following format:
ICH --hpos (H Position) --vpos (V Position)
--hsize (H Size) --vsize (V Size)
