ImagePRO-II • User’s Guide 151
B. Remote Control Protocol
ImagePRO-II Remote Commands
• Query Format 2 (Mask):
ICH --con (connector) --ch (channel) --mask --?
• Query Response 2 : Input Channel Mask Setting in the following format:
ICH --left (Left) --right (Right) --top (Top)
--bottom (Bottom)
fjdo
• Description: Input Manager Settings
• Parameters:
--acq (acquire mode): 0 = Off, 1 = On
--con (active connector): 0-7
0 = DVI, 1 = HD15, 2 = HDMI, 3 = DP, 4 = SDI1, 6 = Logo,
7 = Black
--frz (freeze mode): 0 = Off, 1 = On
--save (save input configuration)
--recall (recall input configuration)
--reset (reset input configuration)
• Query Format:
IMGR --?
• Query Response: Input Manager settings in the following format:
IMGR --acq (acquire mode) –con (active connector) --
frz (freeze mode)
rfkmrq
• Description: Universal Input Settings
• Required parameters:
--con (connector)
--itype (input type), for commands to DVI input settings
• Parameters:
--con (connector): [0..4]
0 = DVI, 1 = HD15, 2 = HDMI,
3 = DP, 4 = SDI1
--deint (deinterlacing type): 0 = MotionAdaptive, 1 = FieldToFrame
--itype (input type): 0 = digital, 1 = analog
--motion (motion threshold): [0..15]
--pulldown (pulldown detection): 0 = Off, 1 = On
• Examples:
UINPUT --con 0 --itype 0 --deint 0
(Update DVI (digital in) input, deinterlacing type to Motion Adaptive
• Query Format:
UINPUT --con (connector) --?
