4. Menu Orientation
Configuring Outputs
Figure 4-22. Output EDID Auto Config Menu
On this menu:
• The Select Output line shows the connector from which to read EDID
information. The default value is DVI.
• Auto Config is a command to read the EDID information of the output device,
determine the preferred resolution, and set the output format to that resolution.
Selecting Auto Config changes the output format of the ImagePRO-II to the
output device’s preferred resolution.
• Status displays a submenu that tells whether the EDID information has been
read. If it has been read, the submenu also displays the name, status, and
preferred resolution of the display device.
sáÉïáåÖ=lìíéìí=bafa=fåÑçêã~íáçå
To view the EDID information of an output display, follow these steps:
1. On the Output EDID Auto Config Menu, select Status.
The Output EDID Status Menu appears, as shown in the following illustration. On
this menu, you can read the EDID information for an output you select.
Figure 4-23. Output EDID Status Menu (sample)
2. Use Output to select an output to read (DVI, HD-15, HDMI, DP).
3. For the output connector you selected, the Status field indicates whether the
connector has read the EDID information correctly. Possible status information
includes:
~ n/a — The EDID information is not available, possibly because no output
device is connected.
~ Checksum Error — The EDID information is corrupt.
~ OK — The EDID information is valid.
OUTPUT EDID AUTO CONFIG
> Select Output DVI
Auto Config
Status >>
Note
Only the DVI-D, HD-15, HDMI, and DisplayPort output
connectors can read EDID information.
OUTPUT EDID STATUS
> Output HD-15
Status OK
Name DELL E172FP
Pref 1280x1024P @60.02
