56 ImagePRO-II • User’s Guide
4. Menu Orientation
Configuring Outputs
Figure 4-32. The Comp/S-Video Adjust Submenu
On this menu, there are four options.:
• HD-15 Pedestal and Comp Pedestal — Enable or disable the 7.5 IRE pedestal
on NTSC composite output. This setting is not available for PAL video.
The Pedestal settings are either On or Off. The default setting is On for NTSC
video.
• HD-15 SC Phase and Comp SC Phase — Set the encoder output subcarrier
phase. The range for this setting is -180 to +180 degrees. The default setting is 0.
pÉííáåÖ=lìíéìí=póåÅ
The Output Sync Settings Submenu lets you specify the sync types for selected outputs.
Access this menu by selecting Sync Settings from the Output Menu.
Figure 4-33. Output Sync Settings Submenu
• For DVI Sync, HDMI Sync, and DP Sync, the available options are:
~ +H+V
~ +H-V
~ -H+V
~ -H-V
The default setting for DVI Sync, HDMI Sync, and DP Sync is +H+V.
• For HD-15 Sync, the available options are:
~ CVBS / YC / SOG/Y / CSync
~ +H+V
COMP/S-VID ADJ
> HD-15 Pedestal Off
Comp Pedestal Off
HD-15 SC Phase 0
Comp SC Phase 0
Note
These options apply only to outputs that support composite
and S-Video formats.
OUT SYNC SETTINGS
> DVI Sync +H+V
HDMI Sync +H+V
DP Sync +H+V
HD-15 Sync SOG/Y
HD-15 SOG/Y Tri-level
