ImagePRO-II • User’s Guide 81
4. Menu Orientation
Using the System Menu
The following illustration shows the USB Backup/Restore Submenu, which you access
from the System Menu.
Figure 4-67. USB Submenu
Using this menu, you can:
• Detect the presence of a USB device.
• Back up and restore ImagePRO-II configuration files. When you connect a flash
drive to the ImagePRO-II, the ImagePRO-II creates a directory titled
ImagePRO2Backup on the drive. All logo images and configuration files are
saved to this directory.
• Download and restore a logo image from another ImagePRO-II.
_~ÅâáåÖ=ré=`çåÑáÖìê~íáçå=cáäÉë
To back up a configuration file to a flash drive, use the following procedure:
1. Insert a formatted flash drive in the ImagePRO-II’s front-panel USB port.
2. From the System Menu, scroll to the USB Backup/Restore Submenu. Select
Backup Config.
The USB Backup Config Submenu appears, as shown in the following
illustration. The navigation cursor appears at the default name for the first backup
file.
Figure 4-68. USB Backup Config Submenu
3. If you wish to change the default name of the backup configuration, press SEL.
Use the ADJUST knob to change the name, as described in Saving an Input
Configuration on page 45. Press SEL again when you complete the name
change.
4. Scroll to Backup Config and press SEL.
A confirmation message appears when the backup is complete.
If the backup operation fails, the message shown in the following illustration
appears. Check that the flash drive is properly formatted and installed, and try
again.
USB BACKUP/RESTORE
> USB Detected No
Backup Config >>
Restore Config >>
Backup Logo >>
Restore Logo >>
USB BACKUP CONFIG
> SysBackup1
Backup Config
(FAT filesystem only)
