ImagePRO-II • User’s Guide 85
4. Menu Orientation
Using the System Menu
To set a static IP address for the ImagePRO-II, use the following procedure:
1. Ensure that the DHCP setting is Off.
2. From your network administrator, obtain a valid IP address, including subnet and
gateway.
3. On the Ethernet Submenu, select Set Static IP.
4. On the Set IP Submenu, select SUB(net). The last character in the first field
becomes available, as indicated by the empty field and an underscore.
You must change the SUB parameter before editing either of the other
parameters.
5. Turn the ADJUST knob to change the first value. As you continue turning the
knob, you can change all three values in this field. Values range from 000 to 255
in all four fields.
6. Press SEL to accept your change in the first field. The last character in the next
field becomes available.
7. Continue until you have created the subnet value you want. Press SEL.
8. Make similar changes in the GW and IP fields.
9. Press SEL to accept your final change.
^ÅÅÉëëáåÖ=íÜÉ=fã~ÖÉmolJff=oÉãçíÉäó
After you have set up the Ethernet options as described in Querying the DHCP
Server and Setting a Static IP Address on page 84, use the following procedure to
set up the ImagePRO-II:
1. On a PC, laptop, or mobile device with the Microsoft Windows OS, open a
command prompt window.
2. Type the IP address and port on the prompt, using the following format:
> telnet xxx.xxx.xxx.xxx 10001
where the x’s represent the ImagePRO-II IP address, and 10001 is the port.
After Ethernet communication is established, the telnet window functions in the
same fashion as a serial COM port communication.
3. Verify with the network administrator that the ImagePRO-II can communicate with
the computer.
Note
If you press ESC at any time before accepting your final
change, all your edits will be removed, and the original values
restored.
