84 ImagePRO-II • User’s Guide
4. Menu Orientation
Using the System Menu
Figure 4-73. Ethernet Submenu (sample)
For example, you can:
• Query the DHCP server for a valid IP address, or turn off this feature.
• Set a static IP address for the ImagePRO-II, along with a subnet mask and
gateway. This feature is available only if DHCP is turned Off.
• Set up the ImagePRO-II connection to a Barco Encore or ScreenPRO-II
Controller.
• View the ImagePRO-II’s IP address.
If there is no internet connection, or if a DHCP server has not been found, the IP
address is 000.000.000.000. In this case, the ImagePRO-II ignores the Ethernet
port.
• View the Media Access Control (MAC) address of the ImagePRO-II’s Ethernet
port.
nìÉêóáåÖ=íÜÉ=ae`m=pÉêîÉê
In the Ethernet Submenu, the default setting for DHCP is On. When DHCP is turned on,
the ImagePRO-II automatically queries the DHCP server for a valid IP address. If the
ImagePRO-II receives an IP address, that address is displayed in the Ethernet Submenu.
When DHCP is off, you can manually enter a static IP address, along with a subnet mask
and gateway, in the Set Static IP Submenu. Consult your network administrator for a valid
IP address, subnet mask and gateway.
pÉííáåÖ=~=pí~íáÅ=fm=^ÇÇêÉëë
When a DHCP server is not available, you can set the ImagePRO-II’s IP address, using the
Set IP Submenu shown in the following illustration.
Figure 4-74. Set IP Submenu (sample)
ETHERNET
> DHCP Off
Set Static IP >>
Remote Control >>
IP 192.168.000.201
M 00:04:A5:20:10:C9
Note
It can take several seconds to obtain an address from the
server. During this time, the SEL button remains lit.
SET IP
> SUB 255.255.255.000
GW 192.168.000.200
IP 192.168.000.201
