K5902094 (451920611693) /02 MDSC-8232
35
5.3.2 DisplayPort mode
About DisplayPort mode
The available DisplayPort (DP) modes for your display are:
• DP 1.2 MST
• DP 1.1 main
• DP 1.1 dual
Please refer to the technical specifications for an overview of accepted video formats.
To select the DisplayPort mode
1. Bring up the OSD main menu.
2. Navigate to the Input Select menu.
3. Enter the DP mode submenu.
4. Select one of the available DisplayPort modes and confirm.
5.3.3 Auto search
About auto search
By enabling the input selection auto search function, the display will automatically detect the connected
source and display it on the screen.
To enable/disable auto search
1. Bring up the OSD main menu.
2. Navigate to the Input Select menu.
3. Enter the Auto search submenu.
4. Enable/Disable auto search as desired and confirm.
5.3.4 Failover input
About failover input
This function allows the display to automatically switch to a failover (backup) source in case the DisplayPort or
Nexxis main source is missing. The display will automatically restore the main source once the signal is back.
The available failover inputs for your display are:
• None
• DVI
• SDI
The failover input can only be selected when both
1. the Auto search function is disabled (see “Auto search”, page 35), and
2. the 2nd Picture Mode function is disabled (see “2nd Picture Mode”, page 36).
If any of both functions are enabled then failover will be disabled and made unavailable. As soon as
both functions are disabled again, failover will be enabled and made available again with the
selected failover input.
The failover input will be activated within about 7 seconds after the main input (DisplayPort or
Nexxis) has been lost.
Advanced operation
