Bard Sherlock 3CG - Sherlock 3 CG TCS Catheter Guidance; Step-by-Step Procedure

16
Instructions For Use
4 Sherlock 3CG™ TCS Catheter Guidance
Step 1: Prepare Device
- Connect the sensor to the Sherlock 3CG™ TCS Display via USB cord.
- Verify that the ECG flatline signal is scrolling.
- Verify the battery charge is sufficient for the procedure.
- Enter Patient Information as needed.
Step 2: Position Patient and Perform Ultrasound Pre-scan
- Refer to the Bard Access Systems’ Ultrasound System Instructions for Use.
Step 3: Measure Catheter Length
- Refer to Bard Access Systems’ Catheter Instructions for Use.
Step 4: Prepare Sensor
- Slide the Fin Assembly onto the sensor until fully seated.
- Place sensor in the sensor holder with the fin and ECG electrodes remaining outside the holder and tighten the cinch ring.
