7
Sherlock 3CG™ Tip Confirmation System
STYLET ICON
Location and direction of stylet tip
under the sensor. The circle represents
the tip of the stylet and the tail
represents the body of the stylet.
STYLET ICON GREEN
Stylet tip at the maximum P-wave
with no initial negative deflection.
DEPTH ICON
Relative stylet depth under
the sensor.
OFF SCREEN ICON
Location of the
approaching stylet tip
SEARCHING FOR SIGNAL ICON
Stylet tip had not been detected.
