930/937 Mulcher (O)
800-00256
MURPHY POWER VIEW OPERATION CONTINUED...
MAIN MENU OPTIONSMAIN MENU OPTIONS
MAIN MENU OPTIONSMAIN MENU OPTIONS
MAIN MENU OPTIONS
This section describes the features listed on the main menu of the PowerView. These menu options are displayed
whenever you touch
MenuMenu
MenuMenu
Menu. The
Arrow Keys Arrow Keys
Arrow Keys Arrow Keys
Arrow Keys allow you to scroll the items, and
Enter Enter
Enter Enter
Enter selects the highlighted
option.
SELECTING A LANGUAGESELECTING A LANGUAGE
SELECTING A LANGUAGESELECTING A LANGUAGE
SELECTING A LANGUAGE
From LANGUAGES, you may select ENGLISH, ESPANOL, FRANCAIS, ITALIANO, or DEUTSCH. The
currently selected language is indicated by an asterisk.
STORED FAULT CODES*STORED FAULT CODES*
STORED FAULT CODES*STORED FAULT CODES*
STORED FAULT CODES*
Request stored fault code information.
ENGINE CONFIGURATION DATA*ENGINE CONFIGURATION DATA*
ENGINE CONFIGURATION DATA*ENGINE CONFIGURATION DATA*
ENGINE CONFIGURATION DATA*
ENGINE CONFG allows you to scroll through engine configuration data.
* This function may not be supported by all manufacturers.
BACKLIGHT ADJUSTMENTBACKLIGHT ADJUSTMENT
BACKLIGHT ADJUSTMENTBACKLIGHT ADJUSTMENT
BACKLIGHT ADJUSTMENT
ADJUST BACKLIGHT allows you to select the desired backlight intensity.
CONTRAST ADJUSTMENTCONTRAST ADJUSTMENT
CONTRAST ADJUSTMENTCONTRAST ADJUSTMENT
CONTRAST ADJUSTMENT
From ADJUST CONTRAST, you may select the desired contrast intensity.
SELECT UNITSSELECT UNITS
SELECT UNITSSELECT UNITS
SELECT UNITS
From SELECT UNITS, you may select how information is displayed. ENGLISH for Imperial units, i.e., PSI, °F or
METRIC KPA, METRIC BAR for IS units, i.e., kPa, Bar, °C.
UTILITIESUTILITIES
UTILITIESUTILITIES
UTILITIES
UTILITIES provide troubleshooting features and displays information about the PowerView configuration.
(See “Utilities Menu”)
FAULTS AND WARNINGSFAULTS AND WARNINGS
FAULTS AND WARNINGSFAULTS AND WARNINGS
FAULTS AND WARNINGS
The PowerView provides two means for detecting faults and warnings: visual LEDs on the casing (See “Faceplate
Features”) and fault indicators on the display.
VISUAL INDICATIONVISUAL INDICATION
VISUAL INDICATIONVISUAL INDICATION
VISUAL INDICATION
· Amber LED (Warning)
· Red LED (Derate / Shutdown)
FAULT INDICATORSFAULT INDICATORS
FAULT INDICATORSFAULT INDICATORS
FAULT INDICATORS
