Basics
8
MAK 3003 Measuring system TIGER / LYNX Operating Instructions, Software version 2.35, BA 190130 (11.07.2022)
3.2 Operating Concept
3.2.1 The software user interface
After starting the system, the main screen appears on the display.
You can call up different screens or operating modes using the soft keys to
the left and right of the display.
Corresponding to the installed measuring equipment type (TIGER, LYNX
HLW, ABO Magyar, V3003, Optimate, ROMEX, V plus or E-TIGER) differ the
start screen and the main menu.
3.2.2 Info line
The info line shows the date and time, information about the operating status
and the software page number.
3.2.3 Softkeys
The softkeys can be assigned various functions, the current meaning of which
is indicated by symbols.
All keys are touch-sensitive, meaning that you don’t need to press them but
simply have to touch them.
