Sampling
32
MAK 3003 Measuring system TIGER / LYNX Operating Instructions, Software version 2.35, BA 190130 (11.07.2022)
8.4 SMV4 sample
The SMV4 probe can only be activated if outputs 90 and 92 are configured.
To read and write tags, Tag Scanner NL-TAG Manuel must be configured.
8.4.1 Procedure
● Select the sample type "NL Sample" at tour start.
When the SMV4 sample is activated, this symbol is displayed in the intake
window.
