Bartec MAK TIGER 3003 - 9 Tank segment monitoring

Tank segment monitoring
39
MAK 3003 Measuring system TIGER / LYNX Operating Instructions, Software version 2.35, BA 190130 (11.07.2022)
9 Tank segment monitoring
The configurable tank segment monitoring makes it possible to fill the milk spe-
cifically into individual tank segments.
If a segment sequence is defined in the configuration, you can only fill the seg-
ments in this sequence.
An arrow above the segment number indicates which segment must be opened.
● Open the displayed segment.
The open segment is marked by a cross below the level indicator.
● Confirm the open segment with the soft key  .
Then the intake is started.
Segment 1 is to be opened
Segment 1 is open
Intake in segment 1
Intake is running in segment 1
