Tank segment monitoring
40
MAK 3003 Measuring system TIGER / LYNX Operating Instructions, Software version 2.35, BA 190130 (11.07.2022)
When the configured segment capacity is reached, a message is output and the
intake is interrupted.
If an overfill quantity is configured, you can continue to fill the segment after
each confirmation of the message until the configured overfill quantity is
reached.
Afterwards, the intake can only take place in another segment.
● Confirm the message.
The next segment to be opened is marked with an arrow.
Segment 3 is to be opened,
Segment 1 is still open.
Segment 1 is full.
Segment 3 is open,
Segment 1 is closed.
The intake can be continued.
( START button).
