Bartec MAK TIGER 3003 - Page 43

Tank segment monitoring
41
MAK 3003 Measuring system TIGER / LYNX Operating Instructions, Software version 2.35, BA 190130 (11.07.2022)
If the configuration does not specify a sequence for the segments, you can
fill them in any sequence.
You can check the fill level of the tank segments outside an intake via the tour
menu (see section 12.13) or with the numeric shortcut key 5 (see section 13.2).
The intake is running in Segment 2.
The intake is finished and can be completed.
