MAK 3003 Measuring system TIGER / LYNX Operating Instructions, Software version 2.35, BA 190130 (11.07.2022)
8 Sampling
The measuring system can be configured so that a single sample, tour sample
or Belgium sample are automatically activated at the start of the tour.
If there is no automatic activation, you can also activate the sampling manu-
ally.
● Touch one of the softkeys to the left of the display to display the hidden
soft keys.
● Touch the soft key TOUR SAMPLE , SINGLE SAMPLE
or BELGIUM SAMPLE
(
*)
to activate or deactivate the respective function.
The corresponding symbol appears on the display:
Tour sample activated
Single sample activated
Belgium sample activated
(
*)
Output 88 must be configured for the Belgium sample!
The "SMV4 sample" must be activated at tour start (see section 8.4).
