Overview of functions
11
MAK 3003 Measuring system TIGER / LYNX Operating Instructions, Software version 2.35, BA 190130 (11.07.2022)
4 Overview of functions
The operating sequence and scope during the round of sampling depend on
the respective equipment and the configuration of the software.
All functions that are available during and outside of a tour are described be-
low.
The actual operating sequence results from the differing combinations of the
individual functions. The following illustrations may therefore deviate from the
displays.
Tour start and tour end
A tour must be started in order to be able to perform intake or discharge pro-
cesses. For the tours, default data may be available that contain all the nec-
essary information.
The tour can also be started without default data. All data must be entered
manually (chapter 5).
Enter supplier number
The data of all intake or discharge processes are recorded and can be
uniquely assigned to each supplier. For this reason, a supplier number must
be entered before each process. The numbers can be recorded in different
ways (chapter 6).
Milk intake
The actual milk intake at the supplier takes place when all the necessary data
have been entered and recorded (chapter 7).
Sampling
Samples can be taken from the collected milk in different ways and filled
(chapter 8).
Tank segment monitoring
The filling level of the tank segments and the filling sequence can be moni-
tored and displayed (chapter 9).
Raw milk separation
During intake, the milk can be filled into separate tank segments according to
its quality. Qualities from 1 (good) to 8 (bad) are possible (chapter 10)
Data transfer
The recorded data are transferred via an Internet connection using the config-
ured FTP server (see chapter 11).
