Basler BE1-11m User Manual

33-2 9424200996
Fault Reporting BE1-11m
Table 33-1. Targets as Displayed
Target
Description
27P-#-A/B/C
Phase Undervoltage, A, B, or C
32-#-A/B/C/T-Over
Power, Phase A, B, C, or Total, Overpower
32-#-A/B/C/T-Under
Power, Phase A, B, C, or Total, Underpower
37-A/B/C
Instantaneous Undercurrent
40Q
Loss of Excitation, Reverse var Based
48
Incomplete Sequence
49RTD-# RTD-#-#
Over/Undertemperature
49TC
Thermal Curve
50-#-A/B/C
Instantaneous Overcurrent, Phase A, B, or C
50-#-Residual
Instantaneous Overcurrent, Residual
50-#-IND GND
Instantaneous Overcurrent, Independent Ground
50-#-Pos SEQ
Instantaneous Overcurrent, Positive-Sequence
50-#-Neg SEQ
Instantaneous Overcurrent, Negative-Sequence
50-#-Unbalance
Instantaneous Overcurrent, Unbalance
50BF
Breaker Failure
51-#-A/B/C
Inverse Overcurrent, Phase A, B, or C
51-#-Residual
Inverse Overcurrent, Residual
51-#-IND GND
Inverse Overcurrent, Independent Ground
51-#-Pos SEQ
Inverse Overcurrent, Positive-Sequence
51-#-Neg SEQ
Inverse Overcurrent, Negative-Sequence
51-#-Unbalance
Inverse Overcurrent, Unbalance
55
Power Factor
59-#-A/B/C
Phase Overvoltage, A, B, or C
59X-#-3V0
Auxiliary Overvoltage, 3V0-3ph VT
59X-#-V1
Auxiliary Overvoltage, Positive-Sequence
59X-#-V2
Auxiliary Overvoltage, Negative-Sequence
59X-#-AUX
Auxiliary Overvoltage, Fundamental VX
59X-#-3RD
Auxiliary Overvoltage, 3
rd
Harmonic VX
60FL
Fuse Loss Detection
62-#
Timer Output
81-#-Over
Frequency, Over
81-#-Under
Frequency, Under
81-#-ROC
Frequency, Rate of Change
86-#
Lockout Function
87-A/B/C
Differential Current, Phase A, B, or C
Analog In #
Remote Analog Input
Target logging for a protective function can be disabled if the function is used in a supervisory or
monitoring capacity. The following paragraphs describe how the BE1-11m is programmed to define which
protective functions log targets.
