9424200996 33-7
BE1-11m Fault Reporting
Fault Summary Report Items
A fault summary report collects several items of information about a fault that can aid in determining why
a fault occurred without having to sort through all of the detailed information available. The following items
are contained in a typical fault summary report.
Product Name
This line reports the product name.
Application Version
This line reports the version of firmware inside the product.
Station ID, Device ID, and User ID
These lines report station, device, and user information as defined by BESTCOMSPlus on the Device Info
screen.
Relay Address
This line reports the communications port address(es) that the report was requested from. The addresses
are assigned using BESTCOMSPlus or the front-panel interface.
Settings File Name
This line reports the name of the settings file that was active at the time of the fault.
Fault Time
This line reports the time and date of the initial trigger of the event. This is based on either the pickup
logic expression or the logic trigger expression becoming true as defined by the Fault Trigger logic. Refer
to Figure 33-8 and Table 33-3, call-out A.
Fault Number
This line reports the sequential number (from 1 to 255) assigned to the report by the BE1-11m.
Event Type
This line reports the type of event that occurred. There are five event categories:
1. Trip: A fault was detected as defined by the pickup expression and the BE1-11m tripped to
clear the fault.
2. Pickup: A fault was detected as defined by the pickup expression but the BE1-11m never
tripped indicating that the fault was cleared by another device.
3. Logic: A fault report was recorded by the logic trigger expression but no fault was detected as
defined by the pickup expression.
4. Breaker Failure: A fault was detected as defined by the pickup expression and the breaker
failure trip became true before the fault was cleared.
5. Forced Trigger: A fault report was triggered through the BESTCOMSPlus interface.
Event Trigger
This line reports the logic variables in the picked up or logic trigger expressions that became true to
trigger the recording of the event.
Active Group
This line reports what setting group was active at the time that the fault occurred.
Fault Type
Indication of phases involved in the fault.
