Basler BE1-11m User Manual

9424200996 59-3
BE1-11m Phase Overvoltage (59P) Test
Step 2: Prepare to monitor the 59P-1 timings. Timing accuracy is verified by measuring the elapsed
time between a sensing voltage change and OUT1 closing.
Step 3: Connect and apply a 120 Vac, three-phase voltage source to terminals C13 (A-phase), C14 (B-
phase), C15 (C-phase), and C16 (Neutral).
Step 4: Step the A-phase voltage up to 130 volts. Measure the time delay and record the result.
Step 5: Repeat step 4 for the 5,000 ms and 10,000 ms time delay settings of Table 59-3. Record the
results.
Step 6: (Optional.) Repeat steps 1 through 5 for the B-phase and C-phase voltage inputs. Note: Be sure
to enable proper target for each phase being tested.
Step 7: (Optional.) Repeat steps 1 through 6 for settings group 1, 2, and 3.
Step 8: (Optional.) Repeat steps 1 through 7 for 59P-2.
Functional Test Report
Pickup Verification
Pickup Setting Range = 1 to 300 V
Pickup Accuracy = ±2% or ±1 V, whichever is greater
Dropout/Pickup Ratio = 98% ±1%
Step
Pickup Setting
Low
Actual Pickup
High
Low*
Actual Dropout
High*
Pass/Fail
6
245.0 V
240.1 V
249.9 V
237.6 V
242.5 V
P / F
7
125.0 V
122.5 V
127.5 V
121.3 V
123.8 V
P / F
7
75.0 V
73.5 V
76.6 V
72.8 V
74.3 V
P / F
* Dropout range is calculated from the pickup setting and may need adjusted based on actual pickup.
Timing Verification
Time Delay Range = 50 to 600,000 ms
Timing Accuracy = ±0.5% or ±2 cycles, whichever is greater
Step
Time Delay Setting
Low
Actual Timing
High
Pass/Fail
4
2,000 ms
1,968 ms
2,032 ms
P / F
5
5,000 ms
4,968 ms
5,032 ms
P / F
5
10,000 ms
9,950 ms
10,050 ms
P / F
