Basler BE1-11m User Manual

9424200996 67-5
BE1-11m Power (32) Test
Reverse Tripping Direction (Overpower)
Pickup Setting Range = 1 to 6,000 Watts for 5A sensing
1 to 1,200 Watts for 1A sensing
Pickup Accuracy = ±3 or ±2 W, whichever is greater
Dropout should occur between 95-99% of the actual pickup value.
Step
Pickup Setting
Low
Actual Pickup
High
Low*
Actual Dropout
High*
Pass/Fail
3
500 W
485 W
515 W
475 W
495 W
P / F
* Dropout range is calculated from the pickup setting and may need adjusted based on actual pickup.
Forward Tripping Direction (Underpower)
Pickup Setting Range = 1 to 6,000 Watts for 5A sensing
1 to 1,200 Watts for 1A sensing
Pickup Accuracy = ±3 or ±2 W, whichever is greater
Reset should occur between 95-99% of the actual pickup value.
Step
Setting
Low
Pickup
High
Low*
Dropout
High*
Pass/Fail
3
500 W
485.0 W
515.0 W
475.0 W
495.0 W
P / F
5
250 W
242.5 W
257.5 W
237.5 W
247.5 W
P / F
5
50 W
48.5 W
51.5 W
47.5 W
49.5 W
P / F
* Reset range is calculated from the pickup setting and may need adjusted based on actual pickup.
Reverse Tripping Direction (Underpower)
Pickup Setting Range = 1 to 6,000 Watts for 5A sensing
1 to 1,200 Watts for 1A sensing
Pickup Accuracy = ±3 or ±2 W, whichever is greater
Reset should occur between 95-99% of the actual pickup value.
Step
Pickup Setting
Low
Actual Pickup
High
Low*
Actual Dropout
High*
Pass/Fail
3
500 W
485 W
515 W
475 W
495 W
P / F
* Reset range is calculated from the pickup setting and may need adjusted based on actual pickup.
