9424200996 69-3
BE1-11m Power Factor (55) Test
Step 3: Connect and apply 5A∠0° to terminals D1 (A-phase polarity) and D2 (A-phase non-polarity) and
a three-phase 69.28 V phase-neutral voltage source to terminals C13 (A-phase), C14 (B-
phase), C15 (C-phase), and C16 (Neutral).
Step 4: Rotate the IA angle in the leading or lagging direction until a pickup occurs. This should occur at
60,000ms ± 300ms. Decrease the IA angle until OUT1 opens. Reset the target. Measure the
time delay and record the result.
Step 5: Repeat step 4 for the time delays in the second and third rows of Table 2. Record the results.
Timing accuracy is ±0.5% or 2 cycles, whichever is greater.
Step 6: (Optional.) Repeat steps 1 through 5 for the B-phase and C-phase voltage inputs taking into
consideration the different current angles. Note: Be sure to enable proper target for each phase
being tested.
Step 7: (Optional.) Repeat steps 1 through 6 for settings group 1, 2, and 3.
Functional Test Report
Pickup Verification Table 2 Row 1
Pickup Setting Range = 0.05 to 0.99 leading/lagging
Pickup Accuracy = ±0.01
Step Pickup Setting Low
High Pass/Fail
Pickup Verification Table 2 Row 2
Pickup Verification Table 2 Row 3
