Error detection and troubleshooting
Compact manual b maXX
®
BM4400, BM4600, BM4700
Document no.: 5.06014.02
65
of 94
8
Error operating system P0202
Error Proprog communicationP203
Error no. Meaning Reaction Troubleshooting
16 Errors while booting IS Execute a restart of b maXX
®
4400
17 Software error: IS Execute a restart of b maXX
®
4400
18 Time slot configuration IS Execute a restart of b maXX
®
4400
19 Time slot - time error IS Execute a restart of b maXX
®
4400;
Change configuration of the time slice opera-
tion system
20 1 = No free memory IS Execute a restart of b maXX
®
4400
21 Invalid error code IS Execute a restart of b maXX
®
4400
22 Invalid warning code IS Execute a restart of b maXX
®
4400
23 False FPGA version IS Contact Baumüller
24 Two position controller: error while writ-
ing to target parameter
IS Ensure that the target parameter is writeable in
these operating conditions and the value to
write is in the valid value margin.
25 Checksum error flash system data IS The system data in the controller flash is invalid
and was replaced by default values. These
default values are written to the flash by switch
-
ing off and on.
26 Power unit is not supported IS Use an appropriate power unit or contact
Baumüller
27 to 31 reserved
Not assigned = 0
Error no. Meaning Reaction Troubleshooting
32 Timeout protocol adjustable Execute a restart of b maXX
®
4400
33 Protocol structure adjustable Execute a restart of b maXX
®
4400
34 Wrong module type adjustable Contact Baumüller
35 Too many data in the telegram adjustable Contact Baumüller
36 Not enough data in telegram adjustable Contact Baumüller
37 Invalid operand adjustable Contact Baumüller
38 Invalid memory type adjustable Test RAM
39 Invalid operand address adjustable Enter a valid address
