Preconditions
Compact manual b maXX
®
BM4400, BM4600, BM4700
Document no.: 5.06014.02 Baumüller Nürnberg GmbH
34
of 94
6.2
6.2 Preconditions
The commissioning is an exemplary checking of the functionality of the device. When
commissioning, your assure yourself if the device is ready for operation.
Commissioning
with Baumüller-
motors
The, furthermore described, exemplary commissioning is specified to Baumüller motors.
In order to reduce your scope of work, you are provided with a motor database, within the
operating software WinBASS II, which provides the most values automatically (reads
out), so that you can concentrate on the checking of the values.
If you, however, choose another configuration (e. g. another encoder), you must enter
more values yourself, because the reading of the data isn’t completely available anymore.
Commissioning of
motors of other
manufacturers
Motors of other manufacturers we have not included into the motor data base. In this case
you must feed all values yourself. However, it is possible to include these motors into the
motor database.
6.3 Preparations
Precondition for the commissioning is that mounting and installation are correctly execut-
ed.
1 Assure, that mounting is correctly executed and especially that all safety instructions
were referred to (see mounting in manual of b maXX
®
4400).
.
2 Assure, that the installation is correctly executed, and that especially all safety instruc-
tions were referred to.
3 WinBASS II must be installed onto the PC/laptop. The controller firmware versions,
which are supported by WinBASS II / ProDrive are to be found in WinBASS II / Pro
-
Drive-Online-Help in the menu ’User indications/supported b maXX devices’.
.
At commissioning you can among other things enter motor- and encoder data in the op-
erating software or wrong values can be corrected. In order, to carry out commissioning
efficiently, it is advantageous, if you have all data when starting with commissioning. Data
for Baumüller motors can be found within the operating software in form of a ’motor data
-
base’.
4 Assure, that you have all necessary data.
NOTE
Figures referring to the next working steps are to be found in the manual of the basic unit b
maXX4400.
NOTE
The controller firmware versions, which are supported by WinBASS II / ProDrive are to be
found in the
WinBASS II / ProDrive Online Help in the menu ’User indications/Supported b maXX
®
devic-
es’, or on the WinBASS II / ProDrive CD in the readme file under ’User indications/Supported
b maXX
®
devices’.
