Commissioning
Compact manual b maXX
®
BM4400, BM4600, BM4700
Document no.: 5.06014.02
35
of 94
6
Motor data
(type plate)
This data is, e. g. on the type plate of the motor, which you use when commissioning.
In this example we are using the motor data base, the values from the chart then only
serve as a purpose of control.
Motor data
(data sheet)
This data is to be found on the data sheet of the motor, which you use when you are com-
missioning.
1)
You can also let the notch position be determined by WinBASS II / ProDrive (see ZFind notch position– on
page 54).
Encoder data
(data sheet)
This data you will find on the data sheet of the encoder, which you use during commis-
sioning.
5 Assure, that the motor fulfills the following conditions:
m equipped with a suitable encoder, in our example: Resolver or SinCos encoder
SRS50
m connected to b maXX
®
4400
m Ready-to-operate
6 Make sure, that switching elements for pulse enable and quickstop clearance are con-
nected to b maXX4400 (e. g. in a switchboard) and are operating. Assure, that the
switches are in off-position (inactive).
7 Assure, that all safety devices are connected line- and motor sided and are ready-to-
operate.
Name Value, e. g. is required for input parameter list/parameters
Motor type, -designation DS 56-M Parameter list/configuration motor
P0050 Motor type key
Rated voltage U
N
330 V Parameter list/configuration motor
P0053 Motor nominal voltage
Rated current I
N
4.0 A Parameter list/configuration motor
P0053 Motor nominal current
Rated speed n
N
3000 RPM Parameter list/configuration motor
P0057 Motor nominal speed
Name Value, e. g. is used to enter parameter list/parameters
Limit current I
peak
14.3 A Parameter list/configuration motor
P0069 Motor peak current
Number of pole pairs 3 Parameter list/configuration motor
P0065 Motor number of pole pairs
Max. Speed n
max.
6000 Parameter list/configuration motor
P0072 Motor maximum speed mechanical
Pole position, if specified
1)
240° Parameter list/configuration motor
P0082 Motor notch position
Name Value, e. g. is used to enter parameter list/parameters
Encoder type Sincos-encoder
Stegmann SRS
50/60
at sine-cosine encoders with HIPERFACE
®
interface
the encoder type is automatically entered via the
HIPERFACE
®
interface
PPR count 1024 Parameter list/configuration encoder/
BM_u_Enc1PulsesPerRev
Encoder type Resolver -
PPR count 1 Parameter list/configuration encoder/
BM_u_Enc1PulsesPerRev
