Preparations
Compact manual b maXX
®
BM4400, BM4600, BM4700
Document no.: 5.06014.02 Baumüller Nürnberg GmbH
36
of 94
6.3
8 Assure, that the encoder for motor control (resolver or sine-cosine encoder) is connect-
ed with the encoder cable to the encoder module BM4-ENC-01 or BM4-ENC-02 in slot
A.
9 If necessary, assure, that the safety relay is plugged in and is connected according to
the instructions.
10Assure, that PC/laptop is connected with a serial cable (RS232/9-pin sub-d connector)
to the plug connection X1 of the controller.Start WinBASS II / ProDrive.
NOTE
The company Baumüller Nürnberg GmbH recommends the usage of optically decoupled
transmitters (e.g. from the company Ratioplast part no. 901SV232C6095 and
part no. 901SV232T6095)
You can get an optically decoupled interface cable as an accessories named programming
cable.
