Supported operation modes of the CANopen device profile DSP402
Application Manual POWERLINK Controlled Node
Document no. 5.13013.04 Baumüller Nürnberg GmbH
16
of 80
3.3
Factor Group (Group of user units)
No prescribed objects available, option
al objects are supported partly .
Field bus object
number
mandatory/
optional
Field bus object name
0x608F SIX 0 = 2 optional position_encoder_resolution
0x6090 SIX 0 = 2 optional velocity_encoder_resolution
0x6092 SIX 0 = 2 optional feed_constant
Velocity Mode (Spee
d control)
All prescribed and partly all optional objects are supported .
Field bus object
number
mandatory/
optional
Field bus object name
0x6042 mandatory vl_target_velocity
0x6043 mandatory vl_velocity_demand
0x6044 mandatory vl_control_effort
0x6045 optional vl_manipulated_velocity
0x6046 SIX 0 = 2 mandatory vl_velocity min_max_amount
0x604D optional vl_pole_number
0x604F optional vl_ramp_function_time
0x6050 optional vl_slow_down_time
0x6051 optional vl_quick_stop_time
Profile Torque
Mode
(Torque control)
One prescribed and two optional objects are supported .
Field bus object
number
mandatory/
optional
Field bus object name
0x6071 mandatory target_torque
0x6072 optional max_torque
0x6077 optional torque_actual_value
