© 2012-2019 Baylis Medical Company Inc. 32 of 48 DMR RFP-100A 3.3 V-13 29-May-2020_EN.docx
RJ45 Cable Connector: Standard RJ45 female Port Connector
Side USB Port: Bulkhead mounting USB-A Connector
Rear USB Port: Bulkhead mounting USB-B Connector
Line-In Connection: Bulkhead BNC Connector
Environmental:
Storage:
• Temperature: -20C to 50C. The unit should be gradually returned to the
operating temperature range before use and stabilized for one hour before
operation
• Relative Humidity: ≤90%, non-condensing
• Atmospheric Pressure: 500 to 1060 millibar
Operating:
• Temperature: 15C to 40C
• Relative Humidity: 15% to 90%, non-condensing
• Atmospheric Pressure: 700 to 1060 millibar
Leakage Current Measurements (No Fault Condition):
Device Source Current < 10 uA
Dispersive Electrode Source Current < 10 uA
Device Sink Current < 10 uA
Dispersive Electrode Sink Current < 10 uA
Enclosure Leakage (Ground Open, Power Normal) < 300 uA
Enclosure Leakage (Ground Open, Power Reversed) < 300 uA
Dielectric Withstand (Hi-Pot) Test:
Mains to Chassis (1500VAC, 1min) PASS
Mains to Applied Parts (4,000 VAC, 1min) PASS
