9.6. LABELING AND SYMBOLS
FRONT PANEL
Defibrillator-proof, Patient Isolated connections
Dispersive (Return) Electrode connection; High
Frequency Isolated Patient Circuit
Connector Cable connection
RF Output OFF
RF Output ON
AC Mains Power
USB-A Port
Set Time
TIME
Cut mode
CUT
Up
Down
