SECTION 9: SPECIFICATIONS
9.1. TECHNICAL SPECIFICATIONS
Model number: RFP-100A
Description: Class I, Defibrillation proof Type CF Equipment
Generator:
RF Energy: 468 kHz, Sinusoidal
Maximum output power of 50 Watts*
Maximum output current of 1.27 A *
Maximum output voltage of 565.77 V *
*Into resistive load range of 100-6000 ohms
300 ohm is the rated “nominal” load
Duty Cycle: Durations from 15 – 1000 ms 5 ms (Device dependant)
Repetition frequency of 1 Hz 5%. Rest period of 3s is
recommended between RF energy applications at 1000ms
duty cycle.
Measurement Accuracy: Impedance Range Accuracy
(Power and Impedance) 100 – 1000 ohm: 10%
1000 – 3200 ohm: 15%
3200 – 6000 ohm: 20%
Count-up Timer: Settable from 1-10 seconds (Device dependent)
Display resolution: 1 second
Accuracy: 0.1 second
Dimensions: Width: 11.25 inches (28.5 cm)
Length: 15.6 inches (39.6 cm)
Height: 7 inches (17.8 cm)
Weight: 20 lb. (9.1 kg)
General:
Input Voltage: 100-240 V~
Current Rating: 5.0A, 50-60 Hz
Fuse Rating: 5.0A/250V, IEC, Slow Blow (Time Lag)
Power Cord Length: 10 feet
Connector Cable
Connection: Keyed Quick Connect female 4 pin
Return Electrode
Connection: Standard male 2-pin for commercial pads
Recommended Dispersive
Electrode: ConMed
®
MacroLyte
®
400-2100
Footswitch Connection: Metal Keyed Quick Connect 4pin
