Table 9.5-3 IEC EMC Specifications (Immunity)
Guidance and Manufacturer’s Declaration – Electromagnetic Immunity
The BMC Radiofrequency Puncture Generator is intended for use in the electromagnetic
environment specified below. The customer or the user of the BMC Radiofrequency
Puncture Generator should assure that it is used in such an environment.
Immunity test
IEC 60601
test level
Compliance
level
Electromagnetic environment
- guidance
Electrostatic
discharge
(ESD)
IEC 61000-4-2
±8 kV contact
±15 kV air
±8 kV contact
±15 kV air
Floors should be wood, concrete or
ceramic tile. If floors are covered
with synthetic material, the relative
humidity should be at least 30%.
Electrical fast
transient/burst
IEC 61000-4-4
±2 kV for
power supply
lines
±1 kV for
input/output
lines
±2 kV for
power supply
lines
±1 kV for
input/output
lines
Mains power quality should be that
of a typical commercial or hospital
environment.
Surge
IEC 61000-4-5
±1 kV
differential
mode
±2 kV common
mode
±1 kV
differential
mode
±2 kV common
mode
Mains power quality should be that
of a typical commercial or hospital
environment.
Voltage dips,
short
interruptions
and voltage
variations on
power supply
input lines
IEC 61000-4-11
0 % UT for 0.5
cycle @ 0°,
45°, 90°, 135°,
180°, 225°,
270° and 315°
0 % UT for 1
cycle and 70%
UT for 25/30
cycles @ 0°
0 % UT for
250/300 cycles
@ 0° and 180°
0 % UT for 0.5
cycle @ 0°,
45°, 90°, 135°,
180°, 225°,
270° and 315°
0 % UT for 1
cycle and 70%
UT for 25/30
cycles @ 0°
0 % UT for
250/300 cycles
Mains power quality should be that
of a typical commercial or hospital
environment. If the user of the
BMC Radiofrequency Puncture
Generator requires continued
operation during power mains
interruptions, it is recommended
that the BMC Radiofrequency
Puncture Generator be powered
from an uninterruptible power
supply or battery.
Power
frequency
(50/60 Hz)
magnetic field
IEC 61000-4-8
30 A/m
30 A/m
Power frequency magnetic fields
should be at levels characteristic of
typical location in a typical
commercial or hospital
environment.
NOTE UT is the a.c. mains voltage prior to application of the test level.
