BayTech DS2-RPC DS4-RPC User Manual

DS-RPC OWNER’S MANUAL
INTRODUCTION TO THE DS-RPC
__________________________________________________________________________________________
4
PROGRAMMABLE FEATURES OF THE DS MODULES
(con’t)
FEATURE DESCRIPTION ACTION PAGE
NO.
DS71-MD2 HOST MODULE
Rings to
Answer(*)
The number of times the modem rings
before it automatically answers.
Default = 2 rings
Enter number of rings to
auto answer
45
Modem to
Modem
Xon/Xoff(*)
ASCII character used to stop or start
transmission of data.
Default = Disabled
Enable/ Disable Modem to
Modem
46
Connectivity
Timeout(*)
Configures the amount of connectivity
(5 to 255 minutes) before modem
disconnects. Default = 60 minutes
Enter timeout in minutes.
Enter 0 to disable
47
Escape
Character(*)
Allows ASCII characters to be
interpreted as commands instead of data.
Default = 43 (+)
Enter the character you wish
to use as an escape
48
Unit ID
Unique ID for DS-Series unit.
Default = DS71 or DS71-MD2
Enter unit ID 48
DS74 PERIPHERAL I/O MODULE
Serial Port
Configuration
Sets serial port speed for each I/O port
on the DS74. Default = 9600, 8, 1, N,
Xon/Xoff Disabled, RTS/DTR Low
Enter baud rate, data bits,
stop bits, parity, Xon/Xoff,
and DTR/RTS line driver
51
Port Device
Name
Unique ID for each I/O port as displayed
on the main menu. Default = Device A,
Device B, Device C, Device D, etc.
Enter port device name 52
Table 1 (con’t)

BayTech DS2-RPC DS4-RPC Specifications

General

Input Voltage	120V
Power over Ethernet (PoE)	No
Managed	Yes
Output Voltage	120V
Protocols	SNMP, HTTP, Telnet
Ports	Ethernet
Mounting	Rack-mountable
Operating Temperature	0°C to 40°C

Summary

Programmable Features of DS Modules

DS71/DS71-MD2 Host Module Features

DS74 Peripheral Module Features

DS73TP Network Module Features

Installation and Cabling

Power and Circuit Breaker Information

Connecting Modules and Peripherals

Detailed Operation and Configuration

Connecting to the DS-RPC

Steps for establishing serial connections using EIA-232, internal, and external modems.

Operating the DS-RPC Interface

How to interact with the DS-RPC via its main menu, select devices, and use ASCII commands.

DS71 and DS71-MD2 Configuration

Detailed guide for configuring DS71/DS71-MD2 serial port, device names, passwords, and other settings.

DS74 Peripheral Module Configuration

Procedures for configuring the DS74 peripheral module's serial port and device names.

DS73TP Network Module Configuration

Comprehensive setup for DS73TP, including IP addresses, subnet, gateway, and DNS.

RPC Operation and Configuration

Controlling and Configuring Receptacles

Instructions for managing RPC receptacles and configuring RPC settings like passwords and names.
