DS-RPC OWNER’S MANUAL
DETAILED OPERATION AND CONFIGURATION
__________________________________________________________________________________________
29
DS71 From the configuration menu, select #2,
“Serial Port Configuration”, followed by
<cr>. The DS unit displays the following
table:
Module 1 Serial Port Configuration :
Port Device
Name
Baud
Rate
Word
Size
Stop
Bits
Parity Xon/
Xmit
Xoff/
Recv
Line
DTR
Drive
RTS
1
EIA-232
9600 8 1 None Off Off High High
Exit/Save.............1 Set Parity...............5
Set Baud Rate.....2 Set Xon/Xoff..........6
Set Word Size.....3 RTS Line Driver...7
Set Stop Bits........4 DTR Line Driver...8
Enter Request :
Select the corresponding number to
configure baud rate, word size, stop bits,
parity..
NOTE: DTR is unchangeable when configuring the serial port..
For example, to change the baud rate to
115.2K, select #2, “Set Baud Rate,” followed
by <cr>.
The DS71 displays the following list of
available baud rates:
1 for 300
2 for 600
3 for 1200
4 for 2400
5 for 4800
6 for 9600
7 for 19200
8 for 38400
9 for 57.6K
A for 76.8K
B for 115.2K
Enter Request :
