DS-RPC OWNER’S MANUAL
DETAILED OPERATION AND CONFIGURATION
__________________________________________________________________________________________
44
Toggle Auto Connect Port feature by
selecting #2, “Enable/Disable,” from the Auto
Connect Port menu followed by <cr>. The
DS71 or DS71-MD2 module displays the
current auto connect port status and asks if
you want to enable. Default Auto Connect
Port is disabled.
Auto Connect Port is ......................Disabled
Enable ? (Y/N, CR for no change):
Type “Y“ for yes followed by <cr> if you
want to enable Auto Connect Port. Type “N“
for no followed by <cr> if you want to disable
Auto Connect Port. Type <cr> for no change.
The DS71 or DS71-MD2 module stores Auto
Connect Port configuration in non-volatile
memory and returns to the Auto Connect Port
menu.
DCD LOGON/LOGOFF When enabled, DCD Logon/Logoff prevents
(DS71 only) unwanted modem connections by requiring
login before a modem connection is
established (DCD high). If a disconnection
occurs (DCD low), the DS-RPC will logoff.
If another connection is established (DCD
high), login will be required before
resuming normal operations.
IMPORTANT: This setting is crucial to the proper operation of
the Auto Connect Port and the Password Security functions. The
J-6 jumper must be in the forward (pin 1-2) position on the board.
The board comes from the factory in this condition. (See Appendix
D for the location of J6.) The EIA-232 port on the DS71 module
should be connected to the external modem via an RJ08X007
Crossed Pin Modular Cable and a 25MRJ45MD-6 MODEM
adapter. Do not move any other jumpers on the board.
