DS-RPC OWNER’S MANUAL
DETAILED OPERATION AND CONFIGURATION
__________________________________________________________________________________________
51
DS74 CONFIGURATION If you are using the Menu Selection Method,
select C, “Configure,” followed by a
carriage return <cr> from the DS-RPC Main
Menu. The following selection menu
appears:
Configuration
Module 1 ................................................1
Module 2 ................................................2
Module 3 ................................................3
Select Port .............................................S
Exit ........................................................X
Enter Request :
If you are using the ASCII Character String
Method, exit main menu, then select the
module to configure. To select Module #2,
type $BT2<cr>. The DS-RPC responds
“Requested Connection Made.” Send the
ASCII configuration command $CONFIG.
The above configuration menu appears.
Select the module number that corresponds
to the DS74 module you want to configure.
The following configuration menu appears:
Copyright (C) Bay Technical Associates 1998
DS71 Data Switch Series – EIA-232 I/O Module
Module 2
Status ..….................................................1
Serial Port Configuration ......................2
Port Device Name …..............................3
Configure Another Module ..................C
Exit .........................................................X
Enter Request :
NOTE: The Serial Port Configuration and the Port Device Name
procedures are thoroughly outlined on page 28 and page 34 of this
manual. Only the differences will be noted in text here.
