DS-RPC OWNER’S MANUAL
DETAILED OPERATION AND CONFIGURATION
__________________________________________________________________________________________
32
NOTE: DTR is unchangeable when configuring the serial port.
When configuring the Host Modem, Xon/Xoff, RTS, and DTR are
hardware settings and, therefore, unchangeable.
For example, to change the baud rate to
115.2K, select #2, “Set Baud Rate,” followed
by <cr>.
The DS71-MD2 displays the following list of
available baud rates:
1 for 300
2 for 600
3 for 1200
4 for 2400
5 for 4800
6 for 9600
7 for 19200
8 for 38400
9 for 57.6K
A for 76.8K
B for 115.2K
Enter Request :
Type "B" for 115.2K baud rate. The DS71-
MD2 responds with the new configuration
status:
Module 1 Serial Port Configuration :
Port Device
Name
Baud
Rate
Word
Size
Stop
Bits
Parity Xon/
Xmit
Xoff/
Recv
Line
DTR
Drive
RTS
2
Host MODEM
115.2K 8 1 None Off Off High High
Exit/Save..….......1 Set Parity...….........5
Set Baud Rate….2 Set Xon/Xoff….......6
Set Word Size….3 RTS Line Driver....7
Set Stop Bits..…..4 DTR Line Driver...8
Enter Request :
