MATERIAL CODE
MATERIAL NAME SPECIFICATIONS LOCATION
00003909 CARBON FILM RESISTOR 1/6270O±5% BELT
R501
00001699 CARBON FILM RESISTOR 1/447O±5% BELT
R500
00003219 CARBON FILM RESISTOR 1/2W47O±5% BELT
R682
00006239 CARBON FILM RESISTOR 1/2W220O±5% BELT
R622,R850
0210145
METAL POLYESTER FILM CAPACITOR
CL21X 100V 104K C5
C708,C709
0210165
METAL POLYESTER FILM CAPACITOR
CL23X 63V 474±5% 5
C702~C707
02608249 CD C11 16V10U±20%5×11 C2.5 BELT
TC81,TC12,TC13,TC584~TC586,TC591~TC597,
TC599,TC800,TC801,TC850,TC851,TC600~TC6
04
02607879 CD C11C 16V47U±20%5×7 C2.5 BELT
TC7,TC8
02608519 CD CD11 16V47U M 5×11 C2.5 BELT
TC9,TC10,TC814,TC569,TC570,TC619,TC620,T
C622,TC623,TC702,TC703,TC587,TC200
02607819 CD
C11C 10V100U±20%5×11 C2.5 BELT
TC1~TC3,TC82
02602229 CD C11C 10V220U±20%6×7 2.5 BELT
TC4,TC5,TC6
02601819 CD C11 16V220U±20%6×12 C5 BELT
TC14,TC11,TC652,TC653,TC80,TC704
02603859 CD C11 16V470U±20%8×12 C5 BELT
TC617,TC618
02600279 CD C11 16V100U±20%6×12 2.5 BELT
TC705
0260048 CD CD11 35V470U±20%10×20 5
TC654~TC663
0260491 CD CD11K 35V680U±20% 13×20 5
TC698~TC701
0390168 INDUCTOR 100UH±10％
0410 SHAPED 12.5mm
L502,L503
0410176
VERTICAL SCREEN SHIELD FILTERING INDUCTOR
10uH±10% 4A 5mm
L508~L514 ③
0410238
VERTICAL SCREEN SHIELD FILTERING INDUCTOR
10uH ±20% 10A 5mm
L508~L514 ③
03901549 MAGNETIC BEADS INDUCTOR R357508 BELT
L515
0390147 INDUCTOR 47UH±5% 0410 SHAPED 10mm
L811
05700049 DIODE 1N4004 BELT
VD500,VD501,VD509
05700039 DIODE 1N4001 BELT
VD1,VD2,VD7
07800329 TRIODE 9014C BELT
V504
07801389 TRIODE 8050D BELT
V500
07803199 TRIODE SS8550 TO-92 BELT
V1,V2,V4
07801519 TRIODE 8550D BELT
V505 ④
07800309 TRIODE 8550C BELT
V505 ④
1090071 OPTIC-ELECTRO CONVERTOR R179AT
XC106
1090077 ELECTRO-OPTIC TRANSFORMER 1792
XC102 ⑤
1090098 ELECTRO-OPTIC TRANSFORMER HK179A
XC102 ⑤
DVD RECEIVER DK2810HD(RU) BLACK
POWER AMPLIFIER BOARD: 2DK2870HD-1 4940418
