0960171 CRYSTAL OSCILLATOR 13.50MHZ 49-S
Y501
0960020 CRYSTAL OSCILLATOR 27.00MHz 49-S
X1
0960226 CRYSTAL OSCILLATOR 4.332MHz 49-s
Y500
1910158 TERMINAL SOCKET 4-8.4-13
XC103
1910194 TERMINAL SOCKET 4-8.4-13/PB-08B
XC104
1860059 SCART SOCKET 111
XC801
1910159 TERMINAL SOCKET CS TERMINAL D02
XC800
1910195 TERMINAL SOCKET AVG-2-07 BLACK
XC102,XC106
1940033 CABLE SOCKET
11P 1.25mm DUAL RANK STRAIGHT INSERT
XS501
1940024 SOCKET 5P 2.0mm
XS201
1940005 SOCKET 6P 2.0mm
XS202,XS106
2122735 FLAT CABLE
4P450 2.5 T2 WITH NEEDLE, TOGETHER DIRECTION 20#
XP101
2150333 FLAT CABLE
8P230 2.0 T2 4PB WITH NEEDLE, TOGETHER DIRECTION
XP105
1990025 EXTERNAL SOURCES SOCKET 6PZ-7
XC100
3580186 RADIATOR 78×49×30 938 NOT OXIDATION POWER AMPLIFIER IC
4490001 SPRING PAD F3 INSTALL RADIATOR
5230707 SOFT SPONGE SPACER 10×10×2 SINGLE-FACED,HARD STICK ON TOP OF INDUCTANCE L508,L513
2122818 FLAT CABLE
8-6/2P350/70 2.5/2.0 T3 WITH NEEDLE, TOGETHER DIRECTION
XP104
4450012 BOLT PAD F3×7.2×0.5 INSTALL RADIATOR
4210005 MACHINE-TAPPING SCREW PM 3×8 BLACK INSTALL RADIATOR
5233174 RUBBER SPACER
9×9×1 SINGLE-FACED WITH GLUE IN REAR SIDE,CENTER HOLE
POSITION OF POWER AMPLIFIER IC SCREW
MATERIAL CODE
MATERIAL NAME SPECIFICATIONS LOCATION
2100003 CONNETION CORDS F0.6 SHAPED 7.5mm W1,W2,W9,W17,W22
2100004 CONNETION CORDS F0.6 SHAPED 10mm W4,W7,W11,W14,W18,W21,W10
2100006 CONNETION CORDS F0.6 SHAPED 12.5mm W5,W6
2100016 CONNETION CORDS F0.6 SHAPEN 18mm W8
2100017 CONNETION CORDS F0.6 SHAPED 20mm W23
0210205 TERYLENE CAPACITOR 630V 102±5% SHAPED 5MM C501
0000274 CARBON FILM RESISTOR 1/4W47O±5% SHAPED 10 R511,R505
0000431 CARBON FILM RESISTOR 1/4W75O±5% SHAPED 10 R503
0000432 CARBON FILM RESISTOR 1/4W150O±5% SHAPED 10 R517
0000362 CARBON FILM RESISTOR 1/4W220O±5% SHAPED 10 R521
DVD RECEIVER DK2810HD(RU) BLACK
POWER BOARD: @5DK1910SI4-3 CEM1 D1.6 SX @UL C043 4940458
