0260656 CD CD288H 16V470U±20% 10×12 5 TC508,TC520
0260657 CD CD288H 16V1000U±20% 10×20 5 TC507,TC510
0260661 CD CD288H 16V2200U±20%13×20 5 TC506,TC509
0260662 CD CD288H 25V470U±20%10×16 5 TC515
0260659 CD CD288H 35V220U±20%10×12 5 TC514
0260660 CD CD288H 50V1U±20%5×11 2 TC503
0260672 CD
CD288H 50V47U±20％6.3×11 2.5
TC502,TC504,TC505
0260673 CD
CD288H 50V470U±20％13×20 5
TC518
0260751 CD CD11K 50V1000U±20%16×25 7.5 TC516,TC517
0390340 VERTICAL INDUCTOR 10uH±10% 5A 12.5×26.5 10mm L508
0390154 MAGNETIC BEADS INDUCTOR R357508 L503,L209
0410010 CHOKE COIL VERTICAL 10UH 1A 5mm L504,L505
0410011 CHOKE COIL VERTICAL 10UH 2A 5mm L506
1000038 FILTER OF POWER NET
SE1989 20mH +∞-0%
L501,L502
0460654 SWITCH POWER TRANSFORMER @BCK-28-0890 UL T501(BCK-28_0890)
0460454 SWITCH POWER TRANSFORMER BC40-0244
T502 ⑥
0460441 SWITCH POWER TRANSFORMER BC40-0726
T502 ⑥
0680026 SCHOTTKY DIODE SR160 D515
0680087 SCHOTTKY DIODE SR560 DO-27 SHAPED R 20.5×8 D510
0680078 SCHOTTKY DIODE SR30 DO-27 SHAPED 17.5 D509
0570006 DIODE 1N4148 D508,D514
0570013 DIODE HER105 D503,D504,D506,D507,D512,D513
0570014 DIODE HER107 D501,D502
0570042 DIODE HER207 SHAPED 12.5mm D505,D511
0570045 DIODE BYW29E-200 TO-220
D516,D517 ⑦
0570047 DIODE ER802
D516,D517 ⑦
05800069 VOLTAGE REGULATOR DIODE 5.1V 1/2W BELT ZD501
0580072 VOLTAGE REGULATOR DIODE 9.1V±5% 1W SHAPED 10mm ZD502
0570032 DIODE 1N5408 D520,D521,D522,D523
0790110
FIELD EFFECT TRANSISTOR
STP460ZFP PLASTIC SEALED TO-220FP
V501
0780026 TRIODE 25551 V502,V503,V504
0690001 CONTROLLABLE SILICON MCR100-6 Q501
0880379 IC L7805 GOLD SEALED TO-220
U508 ⑧
0880247 IC MC7805CT GOLD SEALED TO-220
U508 ⑧
